Voltage Rating：48V AC/60V DC |
Operating Temperature：-40°C to 85°C |
|
Current Rating：15A+2A |
IP Rating：IP67 |
|
Withstand Voltage：500V AC |
Mating Cycle：1000 Times Min (Without load) |
|
Insulation Resistance：20MΩ Min@500VDC |
Wire Gauge：16AWG/1.31mm² + 26AWG/0.120mm² |
Advantages
• Quick Lock
• Power & Signal Hybrid Combination
• IP67 Robust Overmolded Type
• ≥1000 Times Mating Cycles
• Stable Connection in Vibrating Environment
• Waterproof Protective Cap
• RoHS and Reach Compliant
