Home > Products > Coral 2+6 Pin 90° (15A+2A)
Coral 2+6 Pin 90° (15A+2A)
Hits: 0
Brand: Chogori
Price: N/A
Min quantity:
Quantity:
Delivery: In 3 days
Expiry: Long-term
Update date 2025-03-14 15:18

Detail

Applications: For charging & discharging use, cable to panel solution

Advantages
• metal nut reliable connection, smooth feeling
• Power and signal hybrid combination
• Overmold structure, clean and flexible
• RoHS and REACH compliant

Specifications

Mating Cycle：≥200 Cycles

Voltage Rating：32V AC

Operating Temperature：-25°C to 85°C

Pullout Force：<100N

Current Rating：15A + 2A

IP Rating：IP67 Mated

Wire Processing：Solder

Withstand Voltage：650V AC

Salt Spray：5% Nacl, 48H

Wire Gauge：Power 16AWG/ Max
Signal 24AWG/ Max

Insulation  Resistance：>100MΩ at DC 500V

Flammability Rating：UL94V-0 (Plastic Material)
