Specifications
|
Mating Cycle：100 Cycles |
Voltage Rating：48V AC / 60V DC |
Operating Temperature：-25°C to 80°C |
|
Pullout Force：>30N |
Current Rating：2A |
IP Rating：IP67 |
|
Wire Processing：Solder |
Withstand Voltage：500V AC |
Salt Spray：5% Nacl, 48H |
|
Wire Gauge：28AWG / 0.08mm² |
Insulation Resistance：10MΩ at DC 500V |
Flammability Rating：UL94 V-0 (Plastic Material) |
